Name | Coarse sand table | Fine sand table | Slime table | ||
Table size | Model | VS-6STC | VS-6STF | VS-6STS | |
Length (mm) | 4450 | 4450 | 4450 | ||
Drive end width (mm) | 1855 | 1855 | 1855 | ||
Concentrates end width (mm) | 1546 | 1546 | 1546 | ||
Feeding size (mm) | 0.5-2 | 0.074-0.5 | 0-0.074 | ||
Feeding capacity (t/h) | 1-2.5 | 0.5-1.5 | 0.3-0.8 | ||
Feed concentration (%) | 25-30 | 20-25 | 15-25 | ||
Flushing water volume (t/d) | 1-1.8 | 0.7-1 | 0.4-0.7 | ||
Stroke (mm) | 16-22 | 11-16 | 8-16 | ||
Stroke frequency (Times/min) | 240-360 | 240-360 | 240-360 | ||
Beneficiation area (m2) | 7.6 | 7.6 | 7.6 | ||
Table surface shape | Rectangle | Saw-tooth | Triangle | ||
Cross slope (°) | 2.5-4.5 | 1.5-3.5 | 1-2 | ||
Longitudinal slope (°) | 1.4 | 0.92 | ---- | ||
Power (kW) | 1.1 | 1.1 | 1.1 | ||
