Home /Products/Gold Mining Machine/energy & OEM Factory Mesh Screening Circular Vibration Screen Machine China Vibrating Screen Gold Mining

energy & OEM Factory Mesh Screening Circular Vibration Screen Machine China Vibrating Screen Gold Mining

1.0 Sets
MOQ
energy & OEM Factory Mesh Screening Circular Vibration Screen Machine China Vibrating Screen Gold Mining
Features Gallery Product Description Request A Quote
Features
Specifications
Applicable Industries: Energy & Mining
Showroom Location: None
Condition: New
Type: Gravity Separator
Production Capacity: 3-220 Tons Per Hour
Voltage: 380V
Dimension(L*W*H): Depends On Model
Weight: 2100 KG
Warranty: 1 Year
Marketing Type: Ordinary Product
Machinery Test Report: Provided
Video Outgoing-inspection: Provided
Warranty Of Core Components: 1 Year
Core Components: Motor, Other
Key Selling Points: Good Performance
Product Name: Vibrating Screen Machine
Keyword: Circular Vibrating Screen
Deck Type: Double Decks
Sieve Size: 1-40 Mm
Max Feeding Size: 150 Mm
Capacity: 15-150 TPH
Usage: Gravity Ore Separator
Frequency: 800 Shift/minute
Angle: 15-25 Degrees
Weight: 2.1 Tons
Basic Infomation
Payment & Shipping Terms
Packaging Details: Export standard package container loading
Supply Ability: 50 Set/Sets per Month
Product Description
Product Description
Circular vibrating screen (round vibrating screen) is a new type of vibrating screen with multi-layers and high efficiency.
Cylindrical vibrating screen uses cylindrical eccentric shaft exciter and partial block to adjust amplitude, material sieve has
long running line and many sieving specifications. It has the characteristics of reliable structure, strong exciting force, high
sieving efficiency, low vibration noise, durability, convenient maintenance and safe use.

Main Feature
1. Simple and reasonable structure. 2. Full welding connection, more durable. 3. Block-eccentric, more powerful. 4. Low power consumption. 5. Large capacity, small amplitude, high frequency, large angle. 6. Standard accessories, easy maintenance.
Working Principle
The motor makes the exciter swing rotate speedily through the tire coupling. The continuous forced circular motions of sieve box were achieved through the powerful centrifugal force. Under the influence of sieve box, the materiel is tossed forward successively on the mesh. they were classified as thrown up, and the particles smaller than the mesh size were sieved out when they are falling, so that the classification of material could be achieved.
Machine Details
Vibrating Screen is primarily applied in mineral processing separating and stone crushing line. like coal,metallurgical, power generation, building material, water conservancy, light and chemical industries and other industries and a highly efficient screening machine to classify mineral particle and other bulk materials.

Normaly 1-3 layers are most widely used and recommend. While it can customize based on clients' requirement.
Two Options for Screen sieve: High manganese wire woven sieve and polyurethane(PU) sieve
Successful project
Size Information
Model
Layer
Max Feed
Sieve
capacity
Frequency
Angle °
Power
Dimension
size mm
size mm
(t/h)
shift/min
(kw)
(L*W*H)
SZZ600×1200
1
40
1-15
3-20
1000
15-25
2.2
1370×890×330
SZZ2600×1200
2
40
1-15
3-20
1000
15-25
2.2
1370×890×430
SZZ900×1800
1
40
1-15
5-25
1000
15-25
2.2
2150×1358×575
SZZ2900×1800
2
40
1-15
5-30
1000
15-25
3
2489×1358×770
SZZ1250×2500
1
100
1-40
10-100
850
15-20
5.5
2762×1714×680
SZZ21250×2500
2
150
1-40
10-120
850
15-20
5.5
2702×1714×740
SZZ1500×3000
1
150
1-40
15-150
800
15-25
7.5
3320×1449×787
SZZ21500×6000
2
150
1-40
20-220
700
15-25
11
6500x1900x1000
Related Products
Packing&Shipping
1. All the goods will be delivered in 15-30 working days after receiving payment. 2. The machine will be packed in export container. 3. Motors and small parts will be packed in new strong wooden cases that suitable for long distance ocean transportation. 4. We promise that your goods will be shipped to destination timely and safely.
Company Introduction

Our Services & Strength

What we could do for every customer is one-package service:
Such as: mine site early stage exploration, mineral ore analysis test, trial ore processing test, complete process flow sheet
design, full line of mining equipments, after-sales machinery installation, operation training, processing line trial running,
technical support and so on.
Contact US
If you are interested in our products, please don't hesitate to contact us. You can tell me the following questions, so that we can send you accurate quotation soon, including extra discounts! 1. Which machine do you need like gold washing machine, spiral chute, vibrating screen, Jig separator, Shaking table, stone crusher, jaw crusher, impact crusher etc. 2. What is your raw material plan to process Like gold ore, diamond ore, tantalite ore or iron ore, etc. 3. The capacity you need Like 100 tons per hour or 2000 tons per day. 4. Your contact information Both Email and phone number are essential, we can contact you easier.
