Product performance standard: API 11AX
1. Subsurface Sucker Rod Pump
1.1 Rod Pump: Also referred to as “ insert pump” as it is installed inside the tubing it is not necessary to run and pull the tubing out of the well when checking pump. It can enter the tubing with the sucker rod and set, which can greatly reduce the operation cost. According to the setting mode, it is divided into a cup setting and a mechanical setting, and is divided into top support and bottom support according to the support position.
|
Specification Mode |
Seating Type |
Specification Mode |
Seating Type |
Plunger Length m (ft.) |
Tubing (inch) |
|
20-125 25-150 25-175 30-225 |
RHAC RHBC RHAM RHBM |
20-125 20-150 25-200 30-250 |
RWAC RWBC RWAM RWBM |
1.1 - 1.8 (4 - 6) |
2-3/8 2-7/8 3-1/2 |
1.2 Tubing Pump: The barrel is run into the well with tubing, and the plunger is run into the barrel with sucker rod. The bore of the tubing pump is generally larger, so the effect of oil extraction is good, and the output is large for high-yield wells.
|
Specification Mode |
Plunger Length m (ft.) |
Max. OD (mm) |
Tubing (inch) |
Pump Constant m3/d |
Stroke (m) |
|
20-125 25-150 25-175 25-200 25-250 30-275 35-325 40-375 |
1.2 - 1.8 (4 - 6) |
73 - 147 |
2 3/8 2 7/8 3 1/2 4 4 1/2 |
1.14--13.18 |
≤8.0 |
1.3 Special Purpose Pumps
1.3.1 Sand Control Pump: Applicable to oil wells with large sand content, which can effectively reduce the wear of sand on the pump barrel, plunger and valve ball and seat, prolong the service life of the pump, and effectively improve the production of oil wells.
1.3.2 Gas Control Pump: It is suitable for oil wells of high gas radio. It can reduce the impact of gas on production, increase production and extend the service life of pump.
Size of barrel tube : 1 1/4" x 8’ ,
ID: 1-1/4” (32mm),
Length: 8’ (2.44m)
precision finish hardened steel or the carbon nitride
tube heavy wall
Packing
Packaging: exported by Plywooden Cases or Seaworthy Packing
Our Services
We provide pre-market sale of after-sales service.
Company Information
Since 2005 Soright Tech has supplied petroleum machinery products to foreign oilfield market such as Sudan, Algeria, Uzbekistan, Azerbaijan, Oman, Indonesia, and etc. Soright Tech has cooperated with some foreign petroleum company such as Petrodar Operating, OC Touat SH-CNPCI, Petro Energy, CNPC Silk Road etc. Its products have covered the whole domestic oilfields.
Certificates:
Hot-sale Products
Our main products are as follows: subsurface sucker rod pump, sucker rod, tubing & casing, tubing crossover, tubing/casing couplings, stuffing box, thread protector, packing, float shoe and float collar etc.
